Production Process Of Battery Case

  • 1
  • 2

Place of Origin : China

Brand Name : CEI-Kinte

Certification : ISO9001/FEM/ISO14001/OHSAS 18001

Model Number : Customized

MOQ : Negotiable

Price : Negotiable

Packaging Details : Packed with plastic films and wrap with strips

Delivery Time : According to customer's requirement

Payment Terms : Negotiable

Supply Ability : Strong production capacity

R&D : Professional R&D Team

Plant Planning : Overall

Equipment : Automation

Battery pack shape : Square lithium battery/Cylindrical lithium battery;

Battery case material : Aluminum shell/Steel shell/Soft shell

Production process : The latest production technology

Production efficiency : HIgh

Management : Plant Management System

Contact Now

Production process of battery case

The production process of battery steel case: steel strip → electroplating nickel → diffusion heat treatment → steel strip slitting → finished product. The technical feature of the process is to control the nickel plating on both sides of the steel strip and adopt the diffusion heat treatment process to ensure the thickness of the coating, Compactness, adhesion and simultaneous extensibility meet product requirements. Production process flow chart Dividing and shearing unit 330 production line One-meter continuous electroplating production line Bell-type annealing furnace Packaging production line Product storage area.

Production process of battery case:

Steel strip→nickel plating→diffusion heat treatment→strip slitting→finished product

Lithium battery casing treatment process

1. Powder electrostatic spraying process:

The working principle of powder electrostatic spraying technology is almost the same as the electrostatic spraying method of general liquid paint, the difference is that powder spraying is dispersed rather than atomized. It is a coating sprayed by an electrostatic powder spray gun, which makes the powder particles negatively charged while being dispersed. The charged powder particles act on the grounded aluminum case of the power lithium battery through airflow and electrostatic attraction, and then heat, melt and solidify to form a film.

2. Electrophoretic coating process:

The electrophoretic coating process is a coating method that uses an external electric field to cause the particles such as pigments and resins suspended in the electrophoretic solution to migrate in a directional manner and deposit on the surface of the substrate of one of the electrodes. It has the characteristics of water solubility, non-toxicity, and easy automatic control. After the electrophoretic coating process, the aluminum case of the power lithium battery has a soft surface gloss and can resist the acid rain invasion of cement and mortar.

3. Electrochemical surface ceramic technology;

The aluminum casing of the power lithium-ion battery pack adopts plasma-enhanced electrochemical surface ceramic technology, which is of good quality but high cost. The profiles produced by this process have more than 20 colors. The biggest feature is that they can be the same as printed cloth. The surface of the profiles is brightly colored and the decorative effect is the best.

4. Grinding process:

Frosted aluminum profiles can prevent light interference from bright aluminum profiles in certain environments and conditions in architectural decoration. Its surface is as delicate and soft as brocade, which is favored by the market. However, the existing frosted materials must overcome the defects of uneven sand grains and visible patterns on the surface.
